model name
|
fr-s1110gs
|
|
|
chipset
|
rtl8370mb+rtl8231
|
|
|
standards and protocols
|
ieee 802.3、ieee 802.3u、ieee 802.3ab、ieee 802.3x、ieee 802.3z
|
|
|
interface
|
8 x 10/100/1000mbps auto-negotiation ports 2x1000mbps sfp ports
|
|
|
network media |
10base-t: utp category 3, 4, 5 cable (maximum 100m) 100base-tx: utp category 5, 5e cable (maximum 100m) 1000base-t: utp category 5e, 6 cable (maximum 100m) 1000base-sx:62.5μm/50μm mmf(2m~550m) 1000base-lx:62.5μm/50μm mmf(2m~550m)or 10μm smf（2m~5000m）
|
|
|
transfer method
|
store-and-forward
|
|
|
mac address table
|
4k
|
|
|
switching capacity
|
20gbps
|
|
|
buffer
|
1.5mbit
|
|
|
packet forwarding rate
|
14.88mpps
|
|
|
jumbo frame
|
9216bytes
|
|
|
led indicators
|
per device
|
power
|
|
per port
|
link/activity/speed
|
|
|
power supply
|
12v 1a external power supply
|
|
|
power consumption
|
maximum: 5.78w（220v/50hz）
|
|
|
dimensions ( w x d x h )
|
190*100*28mm
|
|
|
environment |
operating temperature: 0℃~45℃ storage temperature: -40℃~70℃ operating humidity: 10%~90% non-condensing storage humidity: 5%~90% non-condensing |
|
