16-port gigabit + 2-port gigabit sfp l2 managed s
model：

comply with ieee 802.3i, ieee 802.3u, ieee802.3x , ieee802.3ab , ieee802.1q , ieee802.1p standards
support web management and the management console
16 x 10/100/1000mbps auto mdi/mdi-x ethernet port,support ports auto mdi/mdix
2*1000mbps sfp ports
supports ieee802.3x flow control for full-duplex mode and backpressure for half-duplex mode
supports qos (quality of service), port mirror, link aggregation protocol
8k entry mac address table of the switch with auto-learning and auto-aging
led indicators for monitoring, link / activity/speed
the built-in power supply, exquisite design, suitable for rack installation.

specifications

model name		fr-s3118gs
chipset		rtl8382m+rtl8218b+3*rtl8231
standards and protocols		ieee 802.3i、ieee 802.3u、ieee 802.3ab、ieee 802.3x、ieee 802.3z、ieee 802.1q、ieee 802.1p
interface		16 x 10/100/1000mbps auto-negotiation ports 2 x 1000mbps sfp ports 1x console port
network media		10base-t: utp category 3, 4, 5 cable (maximum 100m)100base-tx: utp category 5, 5e cable (maximum 100m) 1000base-t: utp category 5e, 6 cable (maximum 100m) 1000base-sx:62.5μm/50μm mmf(2m~550m) 1000base-lx:62.5μm/50μm mmf(2m~550m) or 10μm smf（2m~5000m）
transfer method		store-and-forward
mac address table		8k
switching capacity		36gbps
packet forwarding rate		26.784mpps
packet buffer		4.1mbit
jumbo frame		9216bytes
indicators	per device	power
	per port	link/activity/speed
power supply		100-240vac, 50/60hz internal power
power consumption		maximum: 9.9w (220v/50hz)
dimensions ( w x d x h )		44020844mm
environment		operating temperature: 0℃~45℃ storage temperature: -40℃~70℃ operating humidity: 10%~90% non-condensing storage humidity: 5%~90% non-condensing
