complies with ieee 802.3i, ieee 802.3u, ieee802.3x, ieee802.3az standards
8 10/100mbps auto-negotiation rj45 ports supporting auto-mdi/mdix
supports ieee802.3x flow control for full-duplex mode and backpressure for half-duplex mode
store and forward mode operates
supports mac address auto-learning and auto-aging
supports ieee802.3az protocol power saving
led indicators for monitoring power, link/activity
plastic case
external power adapter supply
|
model |
fr-s1208m |
|
|
chipset |
ip178g |
|
|
standards |
ieee802.3i，ieee802.3u，ieee802.3x，ieee802.3az |
|
|
number of ports
|
8 x 10/100mbps auto-negotiation ports
|
|
|
network media (cable) |
10base-t: utp category 3,4,5 cable (maximum 100m) 100base-t: utp category 5,5e cable (maximum 100m) |
|
|
mac address table |
1k |
|
|
switching capacity |
1.6gbps |
|
|
packet forwarding rate |
745kpps |
|
|
packet buffer |
448k bits |
|
|
jumbo frame |
1552bytes |
|
|
led indicators |
per port |
10/100mbps link/act：green |
|
per device |
power: green |
|
|
power supply |
dc 5v/500ma (external power adapter supply) |
|
|
power consumption |
maximum:1.40w(5v dc) |
|
|
dimensions (l × w × h) |
140*67*26mm |
|
|
environment |
operating temperature: 0℃ - 40℃ storage temperature: -10℃ - 70℃ operating humidity: 10%~90% non-condensing storage humidity: 5%~90% non-condensing |
|
