model name |
fr-wr30210acg-c |
|
|
chipset |
qca9563+qca9886+qca8337 |
|
|
cpu frequency |
775mhz |
|
|
ram crouteracity |
128mbyte(ddr2) |
|
|
rom crouteracity |
32mbyte(spi flash) |
|
|
standards and protocols |
wireless |
5ghz: ieee 802.11ac,ieee 802.11n,ieee 802.11a 2.4ghz: ieee 802.11n,ieee 802.11g,ieee 802.11b |
|
wired |
ieee802.3i,ieee802.3u,ieee802.3ab |
|
|
operating frequency |
2.4ghz & 5ghz |
|
|
signal rate |
2.4ghz: up to 300mbps 5ghz: up to 867mbps |
|
|
modulation |
ieee 802.11b:cck，qpsk，bpsk ieee11g/a:ofdm ieee11n:qpsk，bpsk，16-qam，64-qam ieee11ac:bpsk，qpsk，16qam，64qam，256qam |
|
|
transmit power |
2.4ghz:≦20dbm 5ghz:≦18dbm |
|
|
indicators |
power,wps,wifi |
|
|
interfaces |
1* 10/100/1000mbps wan port(rj45) 2* 10/100/1000mbps lan ports(rj45) |
|
|
button |
reset,wps |
|
|
antenna |
2* single band 2.4g 4dbi build-in antennas, 2* single band 5g 4dbi build-in antennas |
|
|
power supply |
12v/1a adapter |
|
|
dimensions ( w x d x h ) |
180 x 180 x 35mm |
|
|
environment |
operating temperature: 0℃~40℃ storagetemperature:-40℃~70℃operating humidity:10%~90% non-condensing storagehumidity:5%~90% non-condensing |
|
