1 port 10/100/1000mbps rj45 wan port, 4 port 10/100/1000mbps rj45 lan port;
supports 2.4/5g dual-band complicating so fast and more clients can access in;
supports the standard of ieee802.11a/b/g/n/ac
supports up to 1.3gbps wireless transmission rate, with rate adaptive function, can automatically adjust the wireless transmission rate;
automatically select the best channel, can effectively avoid the co-channel interference and improve network stability;
omni-directional antenna, effectively improve the quality of the wireless signal ;
|
model name |
fr-wr2048acgu-c |
|
|
chipset |
mt7621+mt7615d |
|
|
cpu frequency |
880mhz |
|
|
ram capacity |
256mbytes（ddr3） |
|
|
rom capacity |
16mbytes （spi flash） |
|
|
standards and protocols |
wireless |
ieee802.11n、ieee802.11a、ieee802.11g、ieee802.11b、ieee802.11ac |
|
wired |
ieee802.3i,ieee802.3u,ieee802.3ab |
|
|
operating frequency |
2.4ghz & 5ghz |
|
|
signal rate |
2.4ghz: up to 400mbps 5ghz: up to 867mbps |
|
|
modulation |
ieee 802.11b: cck，qpsk，bpsk ieee 11g/a: ofdm ieee 11n:qpsk，bpsk，16-qam，64-qam ieee 11ac:bpsk，qpsk，16qam，64qam，256qam |
|
|
transmit power |
2.4ghz(max):<23dbm 802.11n(mcs7 ht40):19±1.5dbm 5ghz(max):<22dbm 802.11ac(mcs9 vht80):17±1.5dbm |
|
